4.8 Dimensional Drawings of Rack-mounted SERVOPACK Model
4-29
4
4.8.5 Three-phase 200 V: 2.0 kW/3.0 kW
(20AD-R to 30AD-R, 20ADA-R to 30ADA-R)
Cooling fan
Y
Y
CN3
CN1
CN2
(100°)
Y
YASKAWA
YASKAWA
SERVOPACK
SGDM-
Nameplate
180 (7.09)
Heat sink
250 (9.84)
270 (10.63)
285 (11.22)
80 (3.15)
50 (1.97)
6 (0.24)
15 (0.59)*
15*
0.59
Flange
24.5 (0.96)
155.5 (6.12)
6 (0.24)
6 (.024)
7.5 (0.30)*
17.5 (0.69)*
17.5 (0.69)*
7.5 (0.30)*
110 (4.33)
75 (2.95)*
40
(1.57)*
30
(1.18)*
30 (1.18)*
270±0.5 (10.63±0.02)
50±0.5
(1.97±0.02)
7.5 (0.30)*
7.5 (0.30)*
14-pin terminal
M4 mounting screw
CHANGE
MODE/SET
DATA/
POWER
Mounting Hole Diagram
4×M5 tap
(Mounting pitch)
(Mounting pitch)
Ground terminal
2×M4 screws
* Reference length
Units: mm (in)
Approx. mass: 4.0 kg (8.82 lb)
External Terminal Connector
SERVOPACK Connector
Connector
Symbol
SERVOPACK
Connector Model
Manufacturer
CN1 10250-52A2JL Sumitomo 3M Co., Ltd.
CN2 53460-0611 Molex Japan Co., Ltd.
CN3 10214-52A2JL Sumitomo 3M Co., Ltd.
L1C L2CL2 L3L1
200 VAC
50/60 Hz
Three-phase
200 VAC
50/60 Hz
Single-phase
Main circuit
power supply
Control power
supply
