YASKAWA SGDM Series User Manual

4 SERVOPACK Specifications and Dimensional Drawings
4.8.4 Three-phase 200 V: 1.5 kW (15AD-R, 15ADA-R)
4-28
4.8.4 Three-phase 200 V: 1.5 kW (15AD-R, 15ADA-R)
Cooling fan
Terminal
block
-
23D1
CN3
CN1
CN2
YASKAWA
YASKAWA
SERVOPACK
SGDM-
195 (7.68)
17.5 (0.69)
17.5 (0.69)
72 (2.83)
5 (0.20)
2×
φ
5 (φ0.20)
110 (4.33)
180 (7.09)75 (2.95)*
7.5 (0.30)
50±0.5
(1.97±0.02)
180 ± 0.5 (7.09 ± 0.02)
7.5 (0.30)*
12 (0.47)*
48
(1.89)*
24.5 (0.96)
6 (0.24)
6 (0.24)
Heat sink
Flange
Flange
Mounting Hole Diagram
Ground terminal
2×M4 screws
4×M4 screw
Nameplate
(Mounting pitch)
(Mounting pitch)
* Reference length
Units: mm (in)
Approx. mass: 3.0 kg (6.61 lb)
External Terminal Connector
SERVOPACK Connector
Connector
Symbol
SERVOPACK
Connector Model
Manufacturer
CN1 10250-52A2JL Sumitomo 3M Co., Ltd.
CN2 53460-0611 Molex Japan Co., Ltd.
CN3 10214-52A2JL Sumitomo 3M Co., Ltd.
L1C L2CL2 L3L1
200 VAC
50/60 Hz
Three-phase
200 VAC
50/60 Hz
Single-phase
Main circuit
power supply
Control power
supply
