4 SERVOPACK Specifications and Dimensional Drawings
4.8.6 Three-phase 200 V: 5.0 kW (50ADA-R)
4-30
4.8.6 Three-phase 200 V: 5.0 kW (50ADA-R)
50
(1.97)*
35*
(1.38)
6 (0.24)
CN2
35
(1.38)
CN1
CN3
Ve
YASKAWA SERVOPACK 200V
r.
SGDM-50ADA-R
285 (11.22)
270 (10.63)
250 (9.84)
7.5 (0.30)*
17.5 (0.69)*
7.5 (0.30)*
17.5 (0.69)*
230 (9.06)
6 (0.24)
50 (1.97)*
75 (2.95)*
24.5 (0.96)
Nameplate
50 (1.97)
135 (5.31)
50±0.5
(1.97±0.02)
6 (0.24)
7.5 (0.30)*
7.5 (0.30)*
270±0.5 (10.63±0.02)
83
(3.27)*
CHANGE
MODE/SET
DATA/
POWER
L1
L2
L3
L1C
L2C
B1
B2
B3
U
V
W
+ 1
+ 2
Mounting Hole Diagram
4×M5 tap
(Mounting pitch)
(Mounting pitch)
* Reference length
Units: mm (in)
Approx. mass: 5.7 kg (12.57 lb)
(100°)
Heat sink
Flange
6-pin terminal
M5 screw
Ground terminal
M5 screw
5-pin terminal
M4 screw
3-pin terminal
M5 screw
External Terminal Connector
SERVOPACK Connector
Connector
Symbol
SERVOPACK
Connector Model
Manufacturer
CN1 10250-52A2JL Sumitomo 3M Co., Ltd.
CN2 53460-0611 Molex Japan Co., Ltd.
CN3 10214-52A2JL Sumitomo 3M Co., Ltd.
L1C L2CL2 L3L1
200 VAC
50/60 Hz
Three-phase
200 VAC
50/60 Hz
Single-phase
Main circuit
power supply
Control power
supply
