2.1.3 Model SGMGH (1500 min
-1
)
2-6
2.1.3 Model SGMGH (1500 min
-1
)
(1) Without Gears
SGMGH −13 A C A 2 1
∗
∗
1st + 2nd digits:
Rated Output (kW)
Code
05
09
13
20
30
44
55
75
1A
1E
Rated Output
0.45
0.85
1.3
1.8
2.9
4.4
5.5
7.5
11.0
15.0
A
3rd digit: Voltage
A:200V
5th digit: Design Revision Order
6th digit: Shaft End
Code
2
3
5
6
Remarks
Standard
Option
Specifications
Straight without key
Taper 1/10, with parallel key
Taper 1/10, with woodruff key
Straight with key and tap
4th digit: Serial Encoder
Code
2
C
Remarks
Specifications
17-bit absolute encoder
17-bit incremental encoder
Code
A
C
Specifications
Standard
For high-performance machine tool
(4.4 kW or less)
Standard
∗
The number of encoder pulses: 32768 P/Rev.
7th digit: Brake and Oil Seal
Code
1
B
C
D
E
S
Specifications
Without options
With 90-VDC brake
With 24-VDC brake
With oil seal and 90-VDC brake
With oil seal and 24-VDC brake
With oil seal
1st +
2nd
digits
3rd
digit
4th
digit
5th
digit
6th
digit
7th
digit
: Available
