8.8 Operating Using Speed Control with an Internally Set Speed
8-67
8
8.8.2 Input Signal Settings
The following input signals are used to switch the operating speed.
8.8.3 Operating Using an Internally Set Speed
Use ON/OFF combinations of the following input signals to operate with the internally set speeds.
Note: Signal OFF = High level; Signal ON = Low level
Control Mode Switching
When Pn000.1 = 4, 5, or 6, and either /P-CL (/SPD-A) or /N-CL (SPD-B) is OFF (high level), the control
mode will switch.
Example:
When Pn000.1=5: Internally set speed selection Position control (pulse train)
Type Signal
Name
Connector Pin
Number
Meaning
Input /P-CON CN1-41 Switches the servomotor rotation direction.
(/SPD-D) Must be allocated
Input /P-CL CN1-45 Selects the internally set speed.
(/SPD-A) Must be allocated
Input /N-CL CN1-46 Selects the internally set speed.
(/SPD-B) Must be allocated
Input Signal Selection
The following two types of operation can be performed using the internally set speeds:
• Operation with the /P-CON, /P-CL, and /N-CL input signals (pins allocated in factory setting)
• Operation with the /SPD-D, /SPD-A, and /SPD-B input signals
/SPD-D, /SPD-A, and /SPD-B input signals must be allocated with parameter Pn50C. Refer to 7.3.2 Input Circuit Signal
Allocation
.
Input Signal Motor Rotation
Direction
Speed
/P-CON
(/SPD-D)
/P-CL
(/SPD-A)
/N-CL
(/SPD-B)
OFF (high)
OFF (high)
OFF (high)
Forward
Stop at 0 of the internally set speed
OFF (high) ON (low)
Pn301: Internally Set Speed 1 (SPEED1)
ON (low) ON (low)
Pn302: Internally Set Speed 2 (SPEED2)
ON (low)
OFF (high)
Pn303: Internally Set Speed 3 (SPEED3)
ON (low)
OFF (high) OFF (high) Reverse
Stop at 0 of the internally set speed
OFF (high) ON (low)
Pn301: Internally Set Speed 1 (SPEED1)
ON (low) ON (low)
Pn302: Internally Set Speed 2 (SPEED2)
ON (low) OFF (high)
Pn303: Internally Set Speed 3 (SPEED3)
Input Signal Speed
/P-CL (/SPD-A) /N-CL (/SPD-B)
OFF (high) OFF (high)
Pulse train reference input (position control)
OFF (high) ON (low)
Pn301: Internally Set Speed 1 (SPEED1)
ON (low) ON (low)
Pn302: Internally Set Speed 2 (SPEED2)
ON (low) OFF (high)
Pn303: Internally Set Speed 3 (SPEED3)
IMPORTANT
