YASKAWA SGDM Series User Manual

5 Specifications and Dimensional Drawings of Cables and Peripheral Devices
5.8.13 DC Reactor for Harmonic Suppression
5-78
5.8.13 DC Reactor for Harmonic Suppression
(1) Specifications
DC reactor for harmonic suppression is handled by Yaskawa Controls Co., Ltd.
If necessary for harmonic suppression, connect a DC reactor to the SERVOPACK. Note that no terminal for con-
necting a DC reactor is provided to the 6.0 kW or more SERVOPACKs.
Refer to the table below for selecting a DC reactor according to the SERVOPACK capacity. For the connection
method, refer to 6.4.8 DC Reactor for Harmonic Suppression.
Applicable
SERVOPACK Model
SGDM-
DC Reactor
Model
DC Reactor Specifications
Inductance
(mH)
Rated
Current
(A)
Single-phase
100 V
A3BD, A3BDA
−−−
A5BD, A5BDA
01BD, 01BDA
X5063 10.0 1.8
02BD, 02BDA
X5062 4.7 3.5
Single-phase
200 V
A3AD, A3ADA
−−−
A5AD, A5ADA
01AD, 01ADA
X5071 40.0 0.85
02AD, 02ADA
X5070 20.0 1.65
04AD, 04ADA
X5069 10.0 3.3
Three-phase
200 V
05AD, 05ADA
X5061 2.0 4.8
08AD, 08ADA
10AD, 10ADA
15AD, 15ADA
X5060 1.5 8.8
20AD, 20ADA
30AD, 30ADA
X5059 1.0 14.0
50ADA
X5068 0.47 26.8
