1 Outline
1.1.1 Check Items
1-2
1.1 Checking Products
The following procedure is used to check the AC servodrives of Σ-ΙΙ Series products on delivery.
1.1.1 Check Items
Check the following items when Σ-ΙΙ Series products are delivered.
If any of the above items are faulty or incorrect, contact your Yaskawa representative or the dealer from whom
you purchased the products.
1.1.2 Servomotors
Check Items Comments
Are the delivered products the ones
that were ordered?
Check the model numbers marked on the nameplates on the servomo-
tor and SERVOPACK. (Refer to the descriptions of model numbers in
the following section.)
Does the servomotor shaft rotate
smoothly?
The servomotor shaft is normal if it can be turned smoothly by hand.
Servomotors with brakes, however, cannot be turned manually.
Is there any damage?
Check the overall appearance, and check for damage or scratches that
may have occurred during shipping.
AC SERVO MOTOR
YASKAWA ELECTRIC MADE IN JAPAN
TYPE SGMSH-10ACA21
O/N 9W0774 002A
S/N BB2 753000039 DATA 0002
-039
1000 W
5.7
A
3.18 N m
200 V CONT ins F
3000 min
-1
Manufacturing
date
PURODUCT SERVICE
Bauart
gepruft
..
SGMAH and SGMPH
SGMGH / SGMSH / SGMDH
AC SERVO MOTOR
SGMCS-04C3A11
84
200
2.1
W
V
A
N
200
A
4.0
min
Ins.
O/N 9271316-1
S/N DD 9964567890012
YASKAWA ELECTRIC CORPORATION JAPAN
Nameplate
-1
SGMCS
AC SERVO MOTOR
SGMAH-02AAA21
200
200
2.1
W
V
A
N
3000
B
0.637
min
Ins.
O/N 9271316-1
S/N DD 9964567890012
YASKAWA ELECTRIC CORPORATION JAPAN
Servomotor model
Ratings
Serial number
Nameplate
-1
Order number
Servomotor model
Ratings
Order number
Serial number
Servomotor model
Ratings
Order number
Serial number
