5 Specifications and Dimensional Drawings of Cables and Peripheral Devices
5.8.4 Connector Terminal Block Converter Unit
5-60
5.8.4 Connector Terminal Block Converter Unit
(1) Model: JUSP-TA50P
The connection between the connector terminal block converter and the SERVOPACK is shown below.
(2) Dimensional Drawings of Terminal Block
(3) Dimensional Drawing of Cable
1
19
33
16
32
50
1
1
2
49
50

    
 
 !
"  #" 
 $!%&'%
(

)*
(!&%+

,
1
19
33
16
32
50
1
1
2
49
50
Terminal
block (50P)
M3.5 screw
Connector plug (50P)
MR-50RMD2
7 (0.28)
7 (0.28)
15.5 (0.61)
45 (1.77)
15.5
(0.61)
45 (1.77)
3.5 (0.14)3.5 (0.14)
29.5
(1.16)
29.5 (1.16)
2×φ3.5 (φ0.14)
247.5 (9.74)
3.5 (0.14)
3.5 (0.14)
2×M3 tapped holes
247.5 (9.74)
2 (0.08)
20.5
(0.81)
43.5 (1.71)
Can be fixed on DIN rail
(62) (2.44)
Units: mm (in)
With terminal block
cover removed
(19.69 )
500
SERVOPACK end connector (50P)
10150-6000EL (Sumitomo 3M Ltd.)
Shell
10350-52AO-008 (Sumitomo 3M Ltd.)
Cable (black)
AWG#28
25P
UL20276 VW-1SC
Connector terminal block converter unit
end connector (50P)
MRP-50F01 (Honda Tsushin Kogyo Co., Ltd.)
Case
MR-50L
(Honda Tsushin Kogyo Co., Ltd.)
+50
0
+1.97
0
Units: mm (in)
