YASKAWA SGDM Series User Manual

5.3 SERVOPACK Main Circuit Wire Size
5-39
5
5.3.2 Single-phase 100 V
5.3.3 Single-phase 200 V
5.3.4 Three-phase 200 V
External Terminal Name
Terminal
Symbol
SERVOPACK Model SGDM-
A3BD
A3BDA
A5BD
A5BDA
01BD
01BDA
02BD
02BDA
Main circuit power supply input terminals L1, L2
HIV1.25 HIV2.0
Servomotor connection terminals U, V, W
HIV1.25
Control power supply input terminals L1C, L2C
HIV1.25
External regenerative resistor connection
terminals
B1, B2
HIV1.25
Ground terminal
HIV2.0 or more
External Terminal Name
Terminal
Symbol
SERVOPACK Model SGDM-
A3AD
A3ADA
A5AD
A5ADA
01AD
01ADA
02AD
02ADA
04AD
04ADA
Main circuit power supply input terminals L1, L2
HIV1.25 HIV2.0
Servomotor connection terminals U, V, W
HIV1.25
Control power supply input terminals L1C, L2C
HIV1.25
External regenerative resistor connection
terminals
B1, B2
HIV1.25
Ground terminal
HIV2.0 or more
External Terminal Name
Terminal
Symbol
SERVOPACK Model SGDM-
A5AD
A5ADA
08AD
A8ADA
10AD
10ADA
15AD
15ADA
20AD
20ADA
30AD
30ADA
Main circuit power supply input terminals L1, L2, L3
HIV2.0 HIV3.5
Servomotor connection terminals U, V, W
HIV2.0 HIV3.5 HIV5.5
Control power supply input terminals L1C, L2C
HIV1.25
External regenerative resistor connection
terminals
B1, B2
HIV1.25 HIV2.0 HIV3.5
Ground terminal
HIV2.0 or more
External Terminal Name
Terminal
Symbol
SERVOPACK Model SGDM-
50ADA 60ADA 75ADA 1AADA 1EADA
Main circuit power supply input terminals L1, L2, L3
HIV5.5 HIV8 HIV14 HIV22
Servomotor connection terminals U, V, W
HIV8 HIV14 HIV22
Control power supply input terminals L1C, L2C
HIV1.25
External regenerative resistor connection
terminals
B1, B2
HIV5.5 HIV8.0 HIV22
Ground terminal
HIV2.0 or more
