6 Wiring

6.4.8 DC Reactor for Harmonic Suppression

6-30

(2) Connecting a Reactor

Connect a DC reactor as shown in the following diagram. The DC reactor is connected in series to the rectifier

circuit’s output side.

Note: 1. The SERVOPACK 1 and 2 terminals for the DC reactor are short-circuited before shipment.

Remove the lead wire between these two terminals and connect the DC reactor with SERVOPACK.

2. DC reactor is an option (Provided by customer).

DC Reactor

SERVOPACK

DC reactor

Three-phase input
