11 Inspection, Maintenance, and Troubleshooting
11.1.1 Alarm Display Table
11-4
* 1. Occurred when only the software version number is later than 32.
* 2. The alarm meaning differs depending on the SERVOPACK capacity.
•
For the SERVOPACK with a capacity of 5.0 kW or lower:
A.40: Overvoltage detection alarm
A.41: Undervoltage detection alarm
•
For the SERVOPACK with a capacity of 6.0 kW or higher:
A.40: Alarm detecting excessively high/low voltage in the main circuit
A.41: Not used
A.F5
A.F6
Servomotor Disconnection Alarm
*1
The power is not supplied to the servo-
motor through the SERVOPACK
received the Servo ON command.
Available
HLHH
CPF00
Digital Operator
Transmission Error
Digital operator (JUSP-OP02A-2)
fails to communicate with SERVO-
PACK (e.g., CPU error).
N/A
Not decided
CPF01
N/A
A.− −
Not an error Normal operation status
−
HHHL
Table 11.1 Alarm Displays and Outputs (Cont’d)
Alarm
Display
Alarm Name Meaning
Alarm
Reset
Alarm Code Output Servo
Alarm
(ALM)
Output
ALO1 ALO2 ALO3
