3 Specifications and Dimensional Drawings
3.2.3 SGMPH Servomotors With Low-backlash Gears
3-16
* 1. Maximum motor speed is up to 4000 min
-1
at the shaft.
* 2. Gear output torque is expressed using the following equation.
(Gear output torque) = (servomotor output torque) × × (efficiency)
* 3. The instantaneous peak torque values indicated with ∗3 are limited by the gear, so use the following
servomotor instantaneous peak torque. In this case, set torque limit parameters Pn402 and 403 for the
SERVOPACK at 250%.
Note: The no-load torque for a servomotor with gears is high immediately after the servomotor starts, and
it then decreases and becomes stable a few minutes later. This is a common phenomenon caused by
grease being circulated in the gear and not by a faulty gear.
08H1
750
3000
2.39
(338)
1/5
10.2/85
(1440/85)
33.3
(4720)
600 800
2.87
(40.6)
0.765
(10.8)
08HB
1/11
22.3/85
(3160/85)
71
∗3
(10100)
273 363
2.62
(37.1)
0.523
(7.41)
08HC
1/21
42.7/85
(6050/85)
140
(19800)
143 190
2.76
(39.1)
0.663
(9.39)
08H7
1/33
67/85
(9490/85)
206
∗3
(29200)
91 121
2.56
(36.3)
0.455
(6.44)
15H1
1500 4.77 (675)
1/5
20.3/85
(2880/85)
33.3
(4720)
600 800
5.56
(78.7)
1.54
(21.8)
15HB
1/11
44.6/85
(6320/85)
71
(10100)
273 363
6.11
(86.5)
2.09
(29.6)
15GC
1/21
80.1/80
(11300/80)
270
(38200)
143 190
6.00
(85.0)
1.98
(28.0)
15G7
1/33
126/80
(17800/80)
353
∗3
(50000)
91 121
5.14
(72.8)
1.12
(15.8)
(Cont’d)
Servomotor
Model
SGMPH-
Servomotor Gear Output
Moment of Inertia J
×10
-4
kg·m
2
(×10
-3
oz·in·s
2
)
Out-
put
W
Rated
Speed
min
-1
Rated
Torque
Nxm
(ozxin)
Gear
Ratio
Rated
Torque/Effi-
ciency
∗
2
N·m/%
(oz·in/%)
Instanta-
neous
Peak
Torque
N·m
(oz·in)
Rated
Speed
min
-1
Max.
Speed
∗1
min
-1
Motor +
Gears
Gears
1
gear ratio
( )
