YOKOGAWA WT500 User Manual

7-18
IM 760201-01E
Moving the Cursors
• Moving Cursor +
8.
Use the cursor keys to select C1+ under Position.
9.
Press SET to display the cursor position entry box.
10.
Use the cursor keys to set the cursor position.
11.
Press SET or ESC to close the cursor position entry box.
• Moving Cursor x
8.
Use the cursor keys to select C2x under Position.
9.
Press SET to display the cursor position entry box.
10.
Use the cursor keys to set the cursor position.
11.
Press SET or ESC to close the cursor position entry box.
Linking the Cursor Positions
12.
Use the cursor keys to select Linkage.
13.
Press SET to turn Linkage on. The Linkage indicator lights.
7.9 Measuring with Cursors
