Zebra ZT600 Series User Manual

Printer Setup and Operation
18
3. Insert roll or fanfold media into the printer.
Roll Media
Place the roll of media on the media supply spindle. Push the roll as far back as it will go.
Fanfold Media
Fanfold media can be stored behind or under the printer. Depending on where the media is stored,
feed the media from behind or through the bottom access slot.
Rear Feed Bottom Feed

Zebra ZT600 Series Specifications

General

Print Method	Thermal Transfer/Direct Thermal
Print Resolution	203 dpi/8 dots per mm; 300 dpi/12 dots per mm
Maximum Print Width	4.09 in./104 mm
Maximum Print Speed	14 ips (356 mm/s) for 203 dpi, 12 ips (305 mm/s) for 300 dpi
Media Sensors	Reflective and Transmissive
Communication	USB, Serial, Ethernet, Bluetooth
Memory	512 MB Flash
Operating Temperature	5°C to 40°C
