Zebra ZT600 Series User Manual

Routine Maintenance
204
Clean and Lubricate the Cutter Module
If the cutter is not cutting the labels cleanly or if it jams with labels, clean the cutter blades.
1.
2.
Raise the media door.
3. Remove the media from the cutter module.
Caution • For personnel safety, always power off and unplug the printer before performing this
procedure.
Caution • Turn off (O) the printer and disconnect it from the power source before performing the
following procedure.
Turn off (O) the printer and disconnect the AC power cord.

Zebra ZT600 Series Specifications

General

Print Method	Thermal Transfer/Direct Thermal
Print Resolution	203 dpi/8 dots per mm; 300 dpi/12 dots per mm
Maximum Print Width	4.09 in./104 mm
Maximum Print Speed	14 ips (356 mm/s) for 203 dpi, 12 ips (305 mm/s) for 300 dpi
Media Sensors	Reflective and Transmissive
Communication	USB, Serial, Ethernet, Bluetooth
Memory	512 MB Flash
Operating Temperature	5°C to 40°C
