Zebra ZT600 Series User Manual

Printer Setup and Operation
70
Connect to Your Network through the Printer’s Ethernet Port
If you wish to use a wired print server (Ethernet) connection, you may need to connect the printer to your
computer using one of the other available connections. While the printer is connected via one of those
connections, you would configure the printer to communicate with your Local Area Network (LAN) through
the printer’s wired print server.
For additional information about Zebra print servers, refer to the
ZebraNet Wired and
Wireless Print Server User Guide
. To download the latest version of this guide, go to
http://www.zebra.com/zt600-info.
1. Install Zebra Setup Utilities as instructed in Install Zebra Setup Utilities onpage51.
2. Plug the female end of the A/C power cord into the A/C power connector on the back
of the printer.
3. Plug the male end of the A/C power cord into an appropriate power outlet.
100 – 240 VAC
50 – 60 Hz

Zebra ZT600 Series Specifications

General

Print Method	Thermal Transfer/Direct Thermal
Print Resolution	203 dpi/8 dots per mm; 300 dpi/12 dots per mm
Maximum Print Width	4.09 in./104 mm
Maximum Print Speed	14 ips (356 mm/s) for 203 dpi, 12 ips (305 mm/s) for 300 dpi
Media Sensors	Reflective and Transmissive
Communication	USB, Serial, Ethernet, Bluetooth
Memory	512 MB Flash
Operating Temperature	5°C to 40°C
