Printer Configuration and Adjustment
126
TOOLS > PRINT STATION
Use this menu item to fill in variable fields in a label format and print the label using a Human Input Device
(HID), such as a USB keyboard, scale, or barcode scanner. A suitable label format must be stored on the
E: drive of the printer to use this option. See the exercises in Using the USB Host Ports and the NFC
Capabilities on page 247 for an exercise using this capability.
When you plug an HID into one of the printer’s USB host ports, use this user menu to select a form on the
printer’s E: drive. After you have been prompted to fill in each variable ^FN field on the form, you can
specify the desired quantity of labels to print.
For more information about using the ^FN command or the SGD commands related to this feature, refer to
the
Zebra Programming Guide
. You can download a copy of the manual from
http://www.zebra.com/manuals/.
SGD command used:
usb.host.keyboard_input (must be set to ON)
usb.host.template_list
usb.host.fn_field_list
usb.host.fn_field_data
usb.host.fn_last_field
usb.host.template_print_amount
TOOLS
—
PRINT INFORMATION
—
IDLE DISPLAY
—
POWER UP ACTION
—
HEAD CLOSE ACTION
—
LOAD DEFAULTS
—
MEDIA/RIBBON CAL
—
DIAGNOSTIC MODE
—
ENERGY STAR
—
CONFIG INFO TO USB
—
ZBI ENABLED?
—
RUN ZBI PROGRAM
—
STOP ZBI PROGRAM
—
PRINT USB FILE
—
COPY USB FILE TO E:
—
STORE E: FILE TO USB
—
PRINT STATION
—
PASSWORD PROTECT
—
APPLCTR ERR: PAUSE
—
PRINT TEST FORMAT
*
This menu item can be used only if a USB Flash drive with a
suitable label format is inserted into a USB host port on the
printer.
