Zebra ZT600 Series User Manual

Printer Configuration and Adjustment
148
NETWORK > VISIBILITY AGENT
When the printer is connected to a wired or wireless network, it will attempt to connect to Zebra’s Asset
Visibility Service via the Cloud-based Zebra Printer Connector using an encrypted, certificate-
authenticated web socket connection. The printer sends Discovery Data and Settings and Alerts Data.
Data printed via any label formats is NOT transmitted.
To opt out of this feature, disable this setting. For more information, see the “Opting Out of the Asset
Visibility Agent” application note at http://www.zebra.com.
Accepted values:
• ON
• OFF
SGD command used:
weblink.zebra_connector.enable
Printer web page: View and Modify Printer Settings > Network Configuration >
Cloud Connect Settings
NETWORK
—
ACTIVE PRINT SERVER
—
PRIMARY NETWORK
—
WIRED IP ADDRESS
—
WIRED SUBNET MASK
—
WIRED GATEWAY
—
WIRED IP PROTOCOL
—
WIRED MAC ADDRESS
—
WLAN IP ADDRESS
—
WLAN SUBNET MASK
—
WLAN GATEWAY
—
WLAN IP PROTOCOL
—
WLAN MAC ADDRESS
—
ESSID
—
CHANNEL
—
SIGNAL
—
IP PORT
—
IP ALTERNATE PORT
—
PRINT INFORMATION
—
RESET NETWORK
—
VISIBILITY AGENT
—
LOAD DEFAULTS

Zebra ZT600 Series Specifications

General

Print Method	Thermal Transfer/Direct Thermal
Print Resolution	203 dpi/8 dots per mm; 300 dpi/12 dots per mm
Maximum Print Width	4.09 in./104 mm
Maximum Print Speed	14 ips (356 mm/s) for 203 dpi, 12 ips (305 mm/s) for 300 dpi
Media Sensors	Reflective and Transmissive
Communication	USB, Serial, Ethernet, Bluetooth
Memory	512 MB Flash
Operating Temperature	5°C to 40°C
