Zebra ZT600 Series User Manual

Specifications
270
Ribbon Specifications
Standard printers use ribbon that is coated on the outside. An optional ribbon spindle is available to use
ribbon that is coated on the inside. Contact your authorized Zebra reseller for ordering information.
ZT610 ZT620
Ribbon width MINIMUM* 0.79 in. (20 mm) 2 in.** (51 mm**)
Ribbon width MAXIMUM 4.33 in. (110 mm) 6.7 in. (170 mm)
Ribbon length MAXIUMUM 1476 ft (450 m)
Ribbon core inside diameter 1 in. (25 mm)
Ribbon roll outside diameter MAXIMUM 3.2 in. (81.3 mm)
* Zebra recommends using ribbon that is at least as wide as the media to protect the printhead from wear.
** Depending on your application, you may be able to use ribbon narrower than 2 in. (51 mm), as long as the ribbon
is wider than the media being used. To use a narrower ribbon, test the ribbon’s performance with your media to
assure that you get the desired results.

Zebra ZT600 Series Specifications

General

Print Method	Thermal Transfer/Direct Thermal
Print Resolution	203 dpi/8 dots per mm; 300 dpi/12 dots per mm
Maximum Print Width	4.09 in./104 mm
Maximum Print Speed	14 ips (356 mm/s) for 203 dpi, 12 ips (305 mm/s) for 300 dpi
Media Sensors	Reflective and Transmissive
Communication	USB, Serial, Ethernet, Bluetooth
Memory	512 MB Flash
Operating Temperature	5°C to 40°C
