Zebra ZT600 Series User Manual

Printer Configuration and Adjustment
91
Idle Display, Home Menu, and User Menus in the Standard Display
The printer’s control panel includes a display, where you can view the printer’s status or change its
operating parameters. In this section, you will learn how to navigate through the printer’s menu system and
change values for menu items.
Idle Display After the printer completes the power-up sequence, it moves to the Idle Display (Figure 12).
The printer displays the current firmware version and its IP address.
Figure 12 • Idle Display
Home Menu
Use the Home menu (Figure 13) to access the printer’s operating parameters through the
eight user menus (see Adjust Printer Settings on page 92). Click any of the icons in Figure 13 to go to the
descriptions of the menu items for that user menu.
Figure 13 • Home Menu
1
The printer’s current status
2
The printer’s firmware version (top line) and its IP
address (bottom line)
Home menu shortcut
Exit and return to the Idle Display (Figure 12).
1
2

Zebra ZT600 Series Specifications

General

Print Method	Thermal Transfer/Direct Thermal
Print Resolution	203 dpi/8 dots per mm; 300 dpi/12 dots per mm
Maximum Print Width	4.09 in./104 mm
Maximum Print Speed	14 ips (356 mm/s) for 203 dpi, 12 ips (305 mm/s) for 300 dpi
Media Sensors	Reflective and Transmissive
Communication	USB, Serial, Ethernet, Bluetooth
Memory	512 MB Flash
Operating Temperature	5°C to 40°C
