Zebra ZT600 Series User Manual

Printer Setup and Operation
17
Load the Media
Use the instructions in this section for loading roll or fanfold media in the appropriate print mode for your
needs.
Insert the Media into the Printer
The majority of the illustrations in this section show roll media because the media loading path is the same
for both roll and fanfold media.
1. Raise the media door.
2. Remove and discard any tags or labels that are torn or dirty or that are held by adhesives or tape.
Caution • While performing any tasks near an open printhead, remove all rings, watches, hanging
necklaces, identification badges, or other metallic objects that could touch the printhead. You are not
required to turn off the printer power when working near an open printhead, but Zebra recommends it as
a precaution. If you turn off the power, you will lose all temporary settings, such as label formats, and you
must reload them before you resume printing.

Zebra ZT600 Series Specifications

General

Print Method	Thermal Transfer/Direct Thermal
Print Resolution	203 dpi/8 dots per mm; 300 dpi/12 dots per mm
Maximum Print Width	4.09 in./104 mm
Maximum Print Speed	14 ips (356 mm/s) for 203 dpi, 12 ips (305 mm/s) for 300 dpi
Media Sensors	Reflective and Transmissive
Communication	USB, Serial, Ethernet, Bluetooth
Memory	512 MB Flash
Operating Temperature	5°C to 40°C
