Printer Configuration and Adjustment
116
TOOLS > MEDIA/RIBBON CAL
Calibrate the printer to adjust the sensitivity of the media and ribbon sensors.
For complete instructions on how to perform a calibration procedure, see Calibrate the Ribbon and Media
Sensors on page 181.
TOOLS
PRINT INFORMATION
IDLE DISPLAY
POWER UP ACTION
HEAD CLOSE ACTION
LOAD DEFAULTS
MEDIA/RIBBON CAL
DIAGNOSTIC MODE
ENERGY STAR
CONFIG INFO TO USB
ZBI ENABLED?
RUN ZBI PROGRAM
STOP ZBI PROGRAM
PRINT USB FILE
COPY USB FILE TO E:
STORE E: FILE TO USB
PRINT STATION
PASSWORD PROTECT
APPLCTR ERR: PAUSE
PRINT TEST FORMAT
Related ZPL command(s):
~JC
SGD command used:
ezpl.manual_calibration
Control panel key(s):
Hold PAUSE + CANCEL for 2 seconds to initiate calibration.
Printer web page:
The calibration procedure cannot be initiated through the web pages. See
the following web page for settings that are set during sensor calibration:
View and Modify Printer Settings > Calibration
Important • Do not change these settings unless you are told to do
so by Zebra Technical Support or by an authorized service
technician.
