Zebra ZT600 Series User Manual

Printer Setup and Operation
47
Load the Ribbon
Ribbon is used only with thermal transfer labels. For direct thermal labels, do not load ribbon in the printer.
To determine if ribbon must be used with a particular media, see When to Use Ribbon onpage45.
1. Raise the media door.
Note • This section applies only to printers that have the Thermal Transfer option installed.
Caution • While performing any tasks near an open printhead, remove all rings, watches, hanging
necklaces, identification badges, or other metallic objects that could touch the printhead. You are not
required to turn off the printer power when working near an open printhead, but Zebra recommends it as
a precaution. If you turn off the power, you will lose all temporary settings, such as label formats, and you
must reload them before you resume printing.
Important • Use ribbon that is wider than the media to protect the printhead from wear. Ribbon must be
coated on the outside.

Zebra ZT600 Series Specifications

General

Print Method	Thermal Transfer/Direct Thermal
Print Resolution	203 dpi/8 dots per mm; 300 dpi/12 dots per mm
Maximum Print Width	4.09 in./104 mm
Maximum Print Speed	14 ips (356 mm/s) for 203 dpi, 12 ips (305 mm/s) for 300 dpi
Media Sensors	Reflective and Transmissive
Communication	USB, Serial, Ethernet, Bluetooth
Memory	512 MB Flash
Operating Temperature	5°C to 40°C
