Printer Configuration and Adjustment
193
Install the Rewind/Liner Take-Up Plate
The rewind/liner take-up plate is used in different positions for Rewind mode versus Peel mode or
Applicator Mode.
Peel Mode/Applicator Mode
To install the rewind/liner take-up plate for Peel mode or Applicator mode:
1. Loosen the knurled nut (1) on the outside stud on the printer’s base.
