Zebra ZT600 Series User Manual

Using the USB Host Ports and the NFC Capabilities
256
Exercise 4: Enter Data for a Stored File with a USB Keyboard and Print a Label
The Print Station feature allows you to use a USB Human Interface Device (HID), such as a keyboard or a
barcode scanner, to enter ^FN field data into a *.ZPL template file.
1. After performing the previous exercise, plug a USB keyboard into a USB host port.
2. Use the ARROW buttons to scroll to the Tools menu.
3. Press OK.
4. Use the ARROW buttons to scroll to PRINT STATION.
The printer loads any executable files and processes them. The available files are listed.
5. If necessary, use the UP or DOWN ARROW to select the file KEYBOARDINPUT.ZPL.
6. Press the RIGHT SELECT button to choose SELECT.
The printer accesses the file and prompts you for the information in the ^FN fields in the file. In this
case, it prompts you for your name.
7. Type your name, and then press <ENTER>.
The printer prompts for the number of labels to print.
8. Specify the desired quantity of labels, and then press <ENTER> again.
The specified number of labels is printed, with your name in the appropriate fields.

Zebra ZT600 Series Specifications

General

Print Method	Thermal Transfer/Direct Thermal
Print Resolution	203 dpi/8 dots per mm; 300 dpi/12 dots per mm
Maximum Print Width	4.09 in./104 mm
Maximum Print Speed	14 ips (356 mm/s) for 203 dpi, 12 ips (305 mm/s) for 300 dpi
Media Sensors	Reflective and Transmissive
Communication	USB, Serial, Ethernet, Bluetooth
Memory	512 MB Flash
Operating Temperature	5°C to 40°C
