Zebra ZT600 Series User Manual

Printer Configuration and Adjustment
187
Adjust the Printhead Pressure and Toggle Position
The printhead pressure toggles can be adjusted to create more or less pressure, as needed. They can
also be moved from side to side to adjust the pressure in certain areas.
If the toggles are not positioned correctly or adjusted to apply the correct pressure, the following types of
issues may result:
• media and ribbon may slip
• ribbon may wrinkle
• media may move from side to side during printing
• printing may be too light or too dark on one side of the media
Use the lowest printhead pressure necessary to produce good print quality. Higher pressures may cause
premature wear on the printhead elements.
Figure 16 • Printhead Pressure Toggles
1
Inside toggle
2
Outside toggle
21

Zebra ZT600 Series Specifications

General

Print Method	Thermal Transfer/Direct Thermal
Print Resolution	203 dpi/8 dots per mm; 300 dpi/12 dots per mm
Maximum Print Width	4.09 in./104 mm
Maximum Print Speed	14 ips (356 mm/s) for 203 dpi, 12 ips (305 mm/s) for 300 dpi
Media Sensors	Reflective and Transmissive
Communication	USB, Serial, Ethernet, Bluetooth
Memory	512 MB Flash
Operating Temperature	5°C to 40°C
