Zebra ZT600 Series User Manual

Diagnostics and Troubleshooting
228
Indicator Lights
Table 5 • Status of Printer As Shown by Indicator Lights
STATUS light steady green (other lights steady yellow for
2 seconds during printer power-up)
The printer is ready.
PAUSE light steady yellow.
The printer is paused.
STATUS light steady red
SUPPLIES light steady red
The media supply is out. The printer needs attention and
cannot continue without user intervention.
STATUS light steady red
SUPPLIES light flashing red
The ribbon supply is out. The printer needs attention and
cannot continue without user intervention.
STATUS light steady yellow
SUPPLIES light flashing yellow
The printer is in Direct Thermal mode, which does not
require ribbon; however, ribbon is installed in the printer.
STATUS light steady red
PAUSE light steady yellow
The printhead is open. The printer needs attention and
cannot continue without user intervention.
STATUS light steady yellow
The printhead is over temperature.
Caution • The printhead may be hot and could
cause severe burns. Allow the printhead to cool.
STATUS light flashing yellow
This indicator light flashing indicates one of the
following:
• The printhead is under temperature.
• The power supply is over temperature.
• The main logic board (MLB) is over temperature.
STATUS light steady red
PAUSE light steady red
DATA light steady red
The printhead was replaced with one that is not a
genuine Zebra printhead. Install a genuine Zebra
printhead to continue.
STATUS light flashing red
The printer is unable to read the dpi setting of the
printhead.

Zebra ZT600 Series Specifications

General

Print Method	Thermal Transfer/Direct Thermal
Print Resolution	203 dpi/8 dots per mm; 300 dpi/12 dots per mm
Maximum Print Width	4.09 in./104 mm
Maximum Print Speed	14 ips (356 mm/s) for 203 dpi, 12 ips (305 mm/s) for 300 dpi
Media Sensors	Reflective and Transmissive
Communication	USB, Serial, Ethernet, Bluetooth
Memory	512 MB Flash
Operating Temperature	5°C to 40°C
