Printer Setup and Operation
21
3. Rotate the media guide adjustment knob as shown until the media guide slides all the way out.
4.
Caution • The printhead may be hot and could cause severe burns. Allow the printhead to cool.
From the media spindle (1), feed the media under the dancer assembly (2), through the media
sensor (3), and under the printhead assembly (4). Slide the media back until it touches the inside
back wall of the media sensor.
To Next Page
