Abov MC97F60128 User Manual

218
MC97F60128
ABOV Semiconductor Co., Ltd.
PGINTCR (PWM Generator Interrupt Control Register) : 4066H (XSFR)
7
6
5
4
3
2
1
0
–
–
–
–
POVIE
EMGIE
SHTIE
TRGIE
–
–
–
–
R/W
R/W
R/W
R/W
Initial value : 00H
POVIE
Enable or Disable PWM Generator Overflow Interrupt
0
Disable
1
Enable
EMGIE
Enable or Disable Emergency Stop Interrupt
0
Disable
1
Enable
SHTIE
Enable or Disable Shot Stop Interrupt
0
Disable
1
Enable
TRGIE
Enable or Disable TRIG Interrupt
0
Disable
1
Enable
PGIFLAG (PWM Generator Interrupt Flag Register) : 4067H (XSFR)
7
6
5
4
3
2
1
0
–
–
–
–
POVIFR
EMGIFR
SHTIFR
TRGIFR
–
–
–
–
R/W
R/W
R/W
R/W
Initial value : 00H
POVIFR
When PWM generator overflow interrupt occurs, this bit becomes ‘1’. The
flag is cleared only by writing a ‘0’ to the bit. So, the flag should be
cleared by software. Write ‘1’ has no effect.
0
PWM generator overflow interrupt no generation
1
PWM generator overflow interrupt generation
EMGIFR
When emergency stop interrupt occurs, this bit becomes ‘1’. The flag is
cleared only by writing a ‘0’ to the bit. So, the flag should be cleared by
software. Write ‘1’ has no effect.
0
Emergency stop interrupt no generation
1
Emergency stop interrupt generation
SHTIFR
When shot stop interrupt occurs, this bit becomes ‘1’. The flag is cleared
only by writing a ‘0’ to the bit. So, the flag should be cleared by software.
Write ‘1’ has no effect.
0
Shot stop interrupt no generation
1
Shot stop interrupt generation
TRGIFR
When TRIG interrupt occurs, this bit becomes ‘1’. The flag is cleared only
by writing a ‘0’ to the bit. So, the flag should be cleared by software.
Write ‘1’ has no effect.
0
TRIG interrupt no generation
1
TRIG interrupt generation
