MC97F60128
ABOV Semiconductor Co., Ltd.
7. Electrical Characteristics
7.1 Absolute Maximum Ratings
Parameter
Symbol
Rating
Unit
Note
Supply Voltage
VDD
-0.3~+6.5
V
–
Normal Voltage Pin
V
I
-0.3~VDD+0.3
V
Voltage on any pin with respect to VSS
V
O
-0.3~VDD+0.3
V
I
OH
-10
mA
Maximum current output sourced by (I
OH
per I/O pin)
∑I
OH
-80
mA
Maximum current (∑I
OH
)
I
OL
60
mA
Maximum current sunk by (I
OL
per I/O pin)
∑I
OL
120
mA
Maximum current (∑I
OL
)
Total Power
Dissipation
P
T
600
mW
–
Storage
Temperature
T
STG
-65~+150
°C
–
Table 7-1 Absolute Maximum Ratings
NOTE) Stresses beyond those listed under“Absolute Maximum Ratings” may cause permanent damage to the device.
This is a stress rating only and functional operation of the device at any other conditions beyond those indicated in the
operational sections of this specification is not implied. Exposure to absolute maximum rating conditions for extended
periods may affect device reliability.
7.2 Recommended Operating Conditions
(T
A
=-40°C ~ +85°C)
Parameter
Symbol
Conditions
MIN
TYP
MAX
Unit
Operating Voltage
VDD
f
X
= 32 ~ 38kHz
SX-tal
1.8
–
5.5
V
f
X
= 0.4 ~ 4.2MHz
X-tal
(Crystal)
2.0
–
5.5
f
X
= 0.4 ~12MHz
2.7
–
5.5
f
X
= 0.4 ~ 4.2MHz
X-tal
(Ceramic)
1.8
–
5.5
f
X
= 0.4 ~12MHz
2.7
–
5.5
f
X
= 0.5 ~ 8MHz
Internal RC
1.8
–
5.5
f
X
= 1.0 ~ 8MHz
PLL
1.8
–
5.5
Operating Temperature
T
OPR
VDD=1.8~5.5V
-40
–
85
°C
Table 7-2 Recommended Operating Conditions
