11.7.9 Timer/Counter 7 Register Description
The timer/counter 7 register consists of timer 7 counter register (T7CNT), timer 7 data register (T7DR), timer 7 capture
data register (T7CAPR) and timer 7 control register (T7CR).
11.7.10 Register Description for Timer/Counter 7
T7CNT (Timer 7 Counter Register: Read Case, Timer mode only) : 4091H (XSFR)
7
6
5
4
3
2
1
0
T7CNT7
T7CNT6
T7CNT5
T7CNT4
T7CNT3
T7CNT2
T7CNT1
T7CNT0
R
R
R
R
R
R
R
R
Initial value : 00H
T7CNT[7:0]
T7 Counter
T7DR (Timer 7 Data Register: Write Case) : 4091H (XSFR)
7
6
5
4
3
2
1
0
T7DR7
T7DR6
T7DR5
T7DR4
T7DR3
T7DR2
T7DR1
T7DR0
W
W
W
W
W
W
W
W
Initial value : FFH
T7DR[7:0]
T7 Data
T7CAPR (Timer 7 Capture Data Register: Read Case, Capture mode only) : 4091H (XSFR)
7
6
5
4
3
2
1
0
T7CAPR7
T7CAPR 6
T7CAPR 5
T7CAPR 4
T7CAPR 3
T7CAPR 2
T7CAPR 1
T7CAPR 0
R
R
R
R
R
R
R
R
Initial value : 00H
T7CAPR[7:0]
T7 Capture Data
