MC97F60128
ABOV Semiconductor Co., Ltd.
11.12.17 Register Map
Name
Address
Dir
Default
Description
UARTnCR1
4060H/4068H/4070H (XSFR)
R/W
00H
UARTn Control Register 1
UARTnCR2
4061H/4069H/4071H (XSFR)
R/W
00H
UARTn Control Register 2
UARTnCR3
4062H/406AH/4072H (XSFR)
R/W
00H
UARTn Control Register 3
UARTnST
4063H/406BH/4073H (XSFR)
R/W
80H
UARTn Status Register
UARTnBD
4064H/406CH/4074H (XSFR)
R/W
FFH
UARTn Baud Rate Generation Register
UARTnDR
4065H/406DH/4075H (XSFR)
R/W
00H
UARTn Data Register
Table 11-20 UART Register Map (where n = 2,3 and 4)
11.12.18 UART Register Description
UART2/3/4 module consists of UART2/3/4 baud rate generation register (UARTnBD), UART2/3/4 data register
(UARTnDR), UART2/3/4 control register 1 (UARTnCR1), UART2/3/4 control register 2 (UARTnCR2) ,UART2/3/4
control register 3 (UARTnCR3) and UART2/3/4 status register (UARTnST).
11.12.19 Register Description for UART2/3/4
UARTnBD (UARTn Baud Rate Generation Register) : 4064H/406CH/4074H (XSFR), Where n = 2, 3 and 4
7
6
5
4
3
2
1
0
UARTnBD7
UARTnBD6
UARTnBD5
UARTnBD4
UARTnBD3
UARTnBD2
UARTnBD1
UARTnBD0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value : FFH
UARTnBD [7:0]
The value in this register is used to generate internal baud rate. To prevent
malfunction, do not write ‘0’.
