11.17.7 Register Map
Name
Address
Dir
Default
Description
DECCR
40B0H (XSFR)
R/W
00H
FADPCM Decoder Control Register
DFIFOR
40B1H (XSFR)
R/W
00H
FADPCM Decoder FIFO Register
DECDR
40B2H (XSFR)
R/W
00H
FADPCM Decoder Sampling Frequency Data Register
DBDLR
40B3H (XSFR)
R/W
00H
FADPCM Decoder Bundle Register
DODRL
40B4H (XSFR)
R
00H
FADPCM Decoder Result Output Low Register
DODRH
40B5H (XSFR)
R
80H
FADPCM Decoder Result Output High Register
FAFLAG
40B6H (XSFR)
R/W
00H
FADPCM Interrupt Flag Register
VPCR
40C6H (XSFR)
R/W
00H
Voice Prompt Control Register
SFDDNO
40C7H (XSFR)
R/W
00H
Serial Flash Dummy and Data Number
SFCMD
40B7H (XSFR)
R/W
00H
Serial Flash Command Register
VPADDR1
40B8H (XSFR)
R/W
00H
Voice Prompt Address Register 1
VPADDR2
40B9H (XSFR)
R/W
00H
Voice Prompt Address Register 2
VPADDR3
40BAH (XSFR)
R/W
00H
Voice Prompt Address Register 3
VPSIZE1
40BBH (XSFR)
R/W
00H
Voice Prompt Size Register 1
VPSIZE2
40BCH (XSFR)
R/W
00H
Voice Prompt Size Register 2
VPSIZE3
40BDH (XSFR)
R/W
00H
Voice Prompt Size Register 3
VPINF1
40BEH (XSFR)
R/W
00H
Voice Prompt Inform Register 1
VPINF2
40BFH (XSFR)
R/W
00H
Voice Prompt Inform Register 2
Table 11-29 FADPCM Register Map
11.17.8 FADPCM Register Description
The fine ADPCM docoder register consists of the decoder control register (DECCR), decoder FIFO register (DFIFOR),
decoder sampling frequency data register (DECDR), decoder bundle register (DBDLR), decoder result output high/low
register (DODRH/L), voice prompt control register (VPCR), serial flash dummy and data number register (SFDDNO),
serial flash command register (SFCMD), voice prompt address register 1/2/3 (VPADDR1/2/3), voice prompt size
register 1/2/3 (VPSIZE1/2/3) and voice prompt inform register 1/2 (VPINF1/2).
