Abov MC97F60128 User Manual

198
MC97F60128
ABOV Semiconductor Co., Ltd.
11.7.11 Timer/Counter 8 Register Description
The timer/counter 8 register consists of timer 8 PWM period high/low register (T8PPRH/L), timer 8 PWM A duty
high/low register (T8ADRH/L), timer 8 PWM B duty high/low register (T8BDRH/L), timer 8 PWM C duty high/low
register (T8CDRH/L), timer 8 PWM A delay register (T8DLYA), timer 8 PWM B delay register (T8DLYB), timer 8 PWM
C delay register (T8DLYC), timer 8 data register (T8DR), timer 8 capture data register (T8CAPR), timer 8 counter
register (T8CNT), timer 8 control register (T8CR), timer 8 PWM control register 1 (T8PCR1), timer 8 PWM control
register 2 (T8PCR2), timer 8 PWM control register 3 (T8PCR3), timer 8 interrupt status register (T8ISR) and timer 8
interrupt mask register (T8MSK).
11.7.12 Register Description for Timer/Counter 8
T8PPRH (Timer 8 PWM Period High Register : 6-ch PWM mode only) : 4099H (XSFR)
7
6
5
4
3
2
1
0
–
–
–
–
–
–
T8PPRH1
T8PPRH0
–
–
–
–
–
–
R/W
R/W
Initial value : 00H
T8PPRH[1:0]
T8 PWM Period Data High Byte
T8PPRL (Timer 8 PWM Period Low Register : 6-ch PWM mode only) : 4098H (XSFR)
7
6
5
4
3
2
1
0
T8PPRL7
T8PPRL6
T8PPRL5
T8PPRL4
T8PPRL3
T8PPRL2
T8PPRL1
T8PPRL0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value : FFH
T8PPRL[7:0]
T8 PWM Period Data Low Byte
T8ADRH (Timer 8 PWM A Duty High Register : 6-ch PWM mode only) : 409BH (XSFR)
7
6
5
4
3
2
1
0
–
–
–
–
–
–
T8ADRH1
T8ADRH0
–
–
–
–
–
–
R/W
R/W
Initial value : 00H
T8ADRH[1:0]
T8 PWM A Duty Data High Byte
T8ADRL (Timer 8 PWM A Duty Low Register : 6-ch PWM mode only) : 409AH (XSFR)
7
6
5
4
3
2
1
0
T8ADRL7
T8ADRL6
T8ADRL5
T8ADRL4
T8ADRL3
T8ADRL2
T8ADRL1
T8ADRL0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value : 7FH
T8ADRL[7:0]
T8 PWM A Duty Data Low Byte
