11.10.6 Register Map
Name
Address
Dir
Default
Description
SPI2CRH
408FH (XSFR)
R/W
00H
SPI2 Control High Register
SPI2CRL
408EH (XSFR)
R/W
00H
SPI2 Control Low Register
SPI2DR
407FH (XSFR)
R/W
00H
SPI2 Data Register
SPI2SRH
4087H (XSFR)
R/W
00H
SPI2 Status High Register
SPI2SRL
4086H (XSFR)
R/W
00H
SPI2 Status Low Register
Table 11-17 SPI 2 Register Map
11.10.7 SPI 2 Register Description
The SPI 2 register consists of SPI 2 control register (SPI2CRH/L), SPI 2 status register (SPI2SRH/L) and SPI 2 data
register (SPI2DR)
11.10.8 Register Description for SPI 2
SP2DR (SPI 2 Data Register) : 407FH (XSFR)
7
6
5
4
3
2
1
0
SPI2DR7
SPI2DR6
SPI2DR5
SPI2DR4
SPI2DR3
SPI2DR2
SPI2DR1
SPI2DR0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value : 00H
SPI2DR [7:0]
SPI 2 Tx/Rx Data
The data go to the SPI2 Tx FIFO (8 bytes length) if data are written in this
register and the data come out from SPI2 Rx FIFO (8 bytes length) if data are
read.
