Abov MC97F60128 User Manual

213
MC97F60128
ABOV Semiconductor Co., Ltd.
11.8.8 Register Map
Name
Address
Dir
Default
Description
PWMCRH
40A9H (XSFR)
R/W
00H
PWM Generator Control High Register
PWMCRL
40A8H (XSFR)
R/W
00H
PWM Generator Control Low Register
PWMADRH
40ABH (XSFR)
R/W
03H
PWM Generator A Data High Register
PWMADRL
40AAH (XSFR)
R/W
FFH
PWM Generator A Data Low Register
PWMBDRH
40ADH (XSFR)
R/W
00H
PWM Generator B Data High Register
PWMBDRL
40ACH (XSFR)
R/W
00H
PWM Generator B Data Low Register
PWMCNTH
40AFH (XSFR)
R
00H
PWM Generator Counter High Register
PWMCNTL
40AEH (XSFR)
R
00H
PWM Generator Counter Low Register
PWMDLYDR
40A6H (XSFR)
R/W
00H
PWM Generator Delay Data Register
NFILDR
40A7H (XSFR)
R/W
0FH
PWM Generator Noise Filter Data Register
PGINTCR
4066H (XSFR)
R/W
00H
PWM Generator Interrupt Control Register
PGIFLAG
4067H (XSFR)
R/W
00H
PWM Generator Interrupt Flag Register
Table 11-14 10-Bit PWM Generator Register Map
11.8.9 10-Bit PWM Generator Register Description
The 10-bit PWM generator register consists of PWM generator A data high register (PWMADRH), PWM generator A
data low register (PWMADRL), PWM generator B data high register (PWMBDRH), PWM generator B data low
register (PWMBDRL), PWM generator control high register (PWMCRH), PWM generator control low register
(PWMCRL), PWM generator delay data register (PWMDLYDR), PWM generator noise filter data register (NFILDR),
PWM generator interrupt control register (PGINTCR) and PWM generator interrupt flag register (PGIFLAG).
