355
ABOV Semiconductor Co., Ltd.
15. Flash Memory
15.1 Overview
15.1.1 Description
MC97F60128 incorporates flash memory to which a program can be written, erased and overwritten while mounted on
the board. The flash memory can be read by ‘MOVC’ instruction and it can be programmed in OCD, serial ISP mode
or user program mode.
• Flash Size : 128kbytes
• Single power supply program and erase
• Command interface for fast program and erase operation
• Up to 10,000 program/erase cycles at typical voltage and temperature for flash memory
NOTE)
1. The RXE bit of USInCR2/UARTnCR2 register should be disabled before flash memory erase and
write start.
