11.6.6 Register Map
Name
Address
Dir
Default
Description
TnCRH
E3H/4079H/4081H/4089H
R/W
00H
Timer n Control High Register
TnCRL
E2H/4078H/4080H/4088H
R/W
00H
Timer n Control Low Register
TnADRH
E5H/407BH/4083H/408BH
R/W
FFH
Timer n A Data High Register
TnADRL
E4H/407AH/4082H/408AH
R/W
FFH
Timer n A Data Low Register
TnBDRH
E7H/407DH/4085H/408DH
R/W
FFH
Timer n B Data High Register
TnBDRL
E6H/407CH/4084H/408CH
R/W
FFH
Timer n B Data Low Register
Table 11-8 Timer 3/4/5/6 Register Map (where n = 3,4,5 and 6)
11.6.7 Timer/Counter 3/4/5/6 Register Description
The timer/counter 3/4/5/6 register consists of Timer 3/4/5/6 A data high register (TnADRH), Timer 3/4/5/6 A data low
register (TnADRL), Timer 3/4/5/6 B data high register (TnBDRH), Timer 3/4/5/6 B data low register (TnBDRL), Timer
3/4/5/6 control High register (TnCRH) and Timer 3/4/5/6 control low register (TnCRL).
