11.7.8 Register Map
Name
Address
Dir
Default
Description
T7CR
4090H (XSFR)
R/W
00H
Timer 7 Control Register
T7CNT
4091H (XSFR)
R
00H
Timer 7 Counter Register
T7DR
4091H (XSFR)
W
FFH
Timer 7 Data Register
T7CAPR
4091H (XSFR)
R
00H
Timer 7 Capture Data Register
T8CR
4092H (XSFR)
R/W
00H
Timer 8 Control Register
T8PCR1
4093H (XSFR)
R/W
00H
Timer 8 PWM Control Register 1
T8PCR2
4094H (XSFR)
R/W
00H
Timer 8 PWM Control Register 2
T8PCR3
4095H (XSFR)
R/W
00H
Timer 8 PWM Control Register 3
T8ISR
4096H (XSFR)
R/W
00H
Timer 8 Interrupt Status Register
T8MSK
4097H (XSFR)
R/W
00H
Timer 8 Interrupt Mask Register
T8PPRL
4098H (XSFR)
R/W
FFH
Timer 8 PWM Period Low Register
T8PPRH
4099H (XSFR)
R/W
00H
Timer 8 PWM Period High Register
T8ADRL
409AH (XSFR)
R/W
7FH
Timer 8 PWM A Duty Low Register
T8ADRH
409BH (XSFR)
R/W
00H
Timer 8 PWM A Duty High Register
T8BDRL
409CH (XSFR)
R/W
7FH
Timer 8 PWM B Duty Low Register
T8BDRH
409DH (XSFR)
R/W
00H
Timer 8 PWM B Duty High Register
T8CDRL
409EH (XSFR)
R/W
7FH
Timer 8 PWM C Duty Low Register
T8CDRH
409FH (XSFR)
R/W
00H
Timer 8 PWM C Duty High Register
T8DLYA
40A0H (XSFR)
R/W
00H
Timer 8 PWM A Delay Register
T8DLYB
40A1H (XSFR)
R/W
00H
Timer 8 PWM B Delay Register
T8DLYC
40A2H (XSFR)
R/W
00H
Timer 8 PWM C Delay Register
T8DR
40A3H (XSFR)
R/W
FFH
Timer 8 Data Register
T8CAPR
40A4H (XSFR)
R
00H
Timer 8 Capture Data Register
T8CNT
40A5H (XSFR)
R
00H
Timer 8 Counter Register
Table 11-12 Timer 7/8 Register Map
