1. Overview
1.1 Description
The MC97F60128 is an advanced CMOS 8-bit microcontroller with 128 Kbytes of FLASH. This is powerful
microcontroller which provides a highly flexible and cost effective solution to many embedded control applications. This
offers the following features: 128 Kbytes of FLASH, 256 bytes of IRAM, 8,192 bytes of XRAM, general purpose I/O,
basic interval timer, watchdog timer, 8/16-bit timer/counter, 16-bit PPG output, 8-bit PWM output, 10-bit PWM output,
watch timer, buzzer driving port, SPI, UART, I2C, USI, 12-bit A/D converter, 12-bit D/A converter, FADPCM, on-chip
POR, LVR, LVI, on-chip oscillator and clock circuitry. The MC97F60128 also supports power saving modes to reduce
power consumption.
Device name
Flash
XRAM
IRAM
Package
MC97F60128L
128 Kbytes
8,192 bytes
256 bytes
100 LQFP-1414
MC97F68128L
80 LQFP-1212
MC97F68128L14
80 LQFP-1414
MC97F67128LB14
64 LQFP-1414
MC97F66128LB14
64 LQFP-1414
Table 1-1 Ordering Information of MC97F60128
MC97F6x128 L B 14 (T)
MC97F6x128 Family Name
x = 0 100 pin
x = 6 64 pin (type 1)
x = 7 64 pin (type 2)
x = 8 80 pin
Package Type
L LQFP
RoHS
B Halogen Free
Package Body Size
14 14 x 14 mm
2
(MC97F66128/67128/68128)
Packing
(T) Tape & Reel
Figure 1.1 Device Nomenclature
