Abov MC97F60128 User Manual

354
MC97F60128
ABOV Semiconductor Co., Ltd.
14.2.3 Connection of Transmission
Two-pin interface connection uses open-drain(wire-AND bidirectional I/O).
Figure 14.8 Connection of Transmission
14.2.4 Circuit
DSCL
OUT
DSDA
OUT
DSDA
IN
DSCL(Debugger Serial Clock Line)
DSDA(Debugger Serial Data Line)
DSDA
OUT
DSDA
IN
Host Machine(Master)
Target Device(Slave)
VDD
Current source for DSCL to fast 0 to 1 transition in high speed mode
pull
-
up
resistors
Rp
Rp
VDD
DSCL
IN
DSCL
OUT
DSCL
IN
RUNFLAG
IN
VDD
RUNFLAG
OUT
RUNFLAG
IN
RUNFLAG
OUT
RUNFLAG
VDD
VDD
