11.6.8 Register Description for Timer/Counter 3/4/5/6
TnADRH (Timer n A data High Register) : E5H/407BH/4083H/408BH (where n = 3,4,5 and 6)
7
6
5
4
3
2
1
0
TnADRH7
TnADRH6
TnADRH5
TnADRH4
TnADRH3
TnADRH2
TnADRH1
TnADRH0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value : FFH
TnADRH[7:0]
Tn A Data High Byte
TnADRL (Timer n A Data Low Register) : E4H/407AH/4082H/408AH (where n = 3,4,5 and 6)
7
6
5
4
3
2
1
0
TnADRL7
TnADRL6
TnADRL5
TnADRL4
TnADRL3
TnADRL2
TnADRL1
TnADRL0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value : FFH
TnADRL[7:0]
Tn A Data Low Byte
NOTE)
1. Do not write “0000H” in the TnADRH/TnADRL register when
PPG mode
TnBDRH (Timer n B Data High Register) : E7H/407DH/4085H/408DH (where n = 3,4,5 and 6)
7
6
5
4
3
2
1
0
TnBDRH7
TnBDRH6
TnBDRH5
TnBDRH4
TnBDRH3
TnBDRH2
TnBDRH1
TnBDRH0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value : FFH
TnBDRH[7:0]
Tn B Data High Byte
TnBDRL (Timer n B Data Low Register) : E6H/407CH/4084H/408CH (where n = 3,4,5 and 6)
7
6
5
4
3
2
1
0
TnBDRL7
TnBDRL6
TnBDRL5
TnBDRL4
TnBDRL3
TnBDRL2
TnBDRL1
TnBDRL0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value : FFH
TnBDRL[7:0]
Tn B Data Low Byte
