11.15.8 Register Map
Name
Address
Dir
Default
Description
DACCR
40C0H (XSFR)
R/W
00H
D/A Converter Control Register
PGSR
40C1H (XSFR)
R/W
00H
Programmable Gain Selection Register
DACDRH
40C3H (XSFR)
R/W
00H
D/A Converter Data High Register
DACDRL
40C2H (XSFR)
R/W
00H
D/A Converter Data Low Register
DACBRH
40C5H (XSFR)
R
00H
D/A Converter Buffer High Register
DACBRL
40C4H (XSFR)
R
00H
D/A Converter Buffer Low Register
DAOFSCR
40C8H (XSFR)
R/W
00H
D/A Converter Offset Control Register
DACIFCR
40C9H (XSFR)
R/W
00H
D/AC Interface Control Register
DACIFCMD
40CAH (XSFR)
R/W
00H
D/AC Interface Command Register
Table 11-27 DAC Register Map
11.15.9 DAC Register Description
The D/A converter register consists of D/A converter control register (DACCR), D/A converter data high register
(DACDRH), D/A converter data low register (DACDRL), D/A converter buffer high register (DACBRH), D/A converter
buffer low register (DACBRL) and programmable gain selection register (PGSR).
