MC97F60128
ABOV Semiconductor Co., Ltd.
11.11.6 Register Map
Name
Address
Dir
Default
Description
SPI3CR
400DH (XSFR)
R/W
00H
SPI3 Control Register
SPI3DR
400EH (XSFR)
R/W
00H
SPI3 Data Register
SPI3SR
400FH (XSFR)
R/W
00H
SPI3 Status Register
Table 11-18 SPI 3 Register Map
11.11.7 SPI 3 Register Description
The SPI 3 register consists of SPI 3 control register (SPI3CR), SPI 3 status register (SPI3SR) and SPI 3 data register
(SPI3DR)
11.11.8 Register Description for SPI 3
SPI3DR (SPI 3 Data Register) : 400EH (XSFR)
7
6
5
4
3
2
1
0
SPI3DR7
SPI3DR6
SPI3DR5
SPI3DR4
SPI3DR3
SPI3DR2
SPI3DR1
SPI3DR0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value : 00H
SPI3DR [7:0]
SPI 3 Data
When it is written a byte to this data register, the SPI 3 will start an operation.
