Abov MC97F60128 User Manual

103
MC97F60128
ABOV Semiconductor Co., Ltd.
9.10 P7 Port
9.10.1 P7 Port Description
P7 is 8-bit I/O port. P7 control registers consist of P7 data register (P7), P7 direction register (P7IO), P7 pull-up resistor
selection register (P7PU) and P7 open-drain selection register (P7OD) . Refer to the port function selection registers
for the P7 function selection.
9.10.2 Register description for P7
P7 (P7 Data Register): C0H
7
6
5
4
3
2
1
0
P77
P76
P75
P74
P73
P72
P71
P70
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value: 00H
P7[7:0]
I/O Data
P7IO (P7 Direction Register): C9H
7
6
5
4
3
2
1
0
P77IO
P76IO
P75IO
P74IO
P73IO
P72IO
P71IO
P70IO
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value: 00H
P7IO[7:0]
P7 Data I/O Direction
0
Input
1
Output
P7PU (P7 Pull-up Resistor Selection Register): A7H
7
6
5
4
3
2
1
0
P77PU
P76PU
P75PU
P74PU
P73PU
P72PU
P71PU
P70PU
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value: 00H
P7PU[7:0]
Configure Pull-up Resistor of P7 Port
0
Disable
1
Enable
P7OD (P7 Open-drain Selection Register): 4017H (XSFR)
7
6
5
4
3
2
1
0
P77OD
P76OD
P75OD
P74OD
P73OD
P72OD
P71OD
P70OD
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value: 00H
P7OD[7:0]
Configure Open-drain of P7 Port
0
Push-pull output
1
Open-drain output
