Abov MC97F60128 User Manual

67
MC97F60128
ABOV Semiconductor Co., Ltd.
Address
Function
Symbol
R/W
@Reset
7
6
5
4
3
2
1
0
4060H
UART2 Control Register 1
UART2CR1
R/W
–
–
0
0
0
0
0
–
4061H
UART2 Control Register 2
UART2CR2
R/W
0
0
0
0
0
0
0
0
4062H
UART2 Control Register 3
UART2CR3
R/W
–
0
–
–
–
0
0
0
4063H
UART2 Status Register
UART2ST
R/W
1
0
0
0
0
0
0
0
4064H
UART2 Baud Rate Generation Register
UART2BD
R/W
1
1
1
1
1
1
1
1
4065H
UART2 Data Register
UART2DR
R/W
0
0
0
0
0
0
0
0
4066H
PWM Generator Interrupt Control Register
PGINTCR
R/W
–
–
–
–
0
0
0
0
4067H
PWM Generator Interrupt Flag Register
PGIFLAG
R/W
–
–
–
–
0
0
0
0
4068H
UART3 Control Register 1
UART3CR1
R/W
–
–
0
0
0
0
0
–
4069H
UART3 Control Register 2
UART3CR2
R/W
0
0
0
0
0
0
0
0
406AH
UART3 Control Register 3
UART3CR3
R/W
–
0
–
–
–
0
0
0
406BH
UART3 Status Register
UART3ST
R/W
1
0
0
0
0
0
0
0
406CH
UART3 Baud Rate Generation Register
UART3BD
R/W
1
1
1
1
1
1
1
1
406DH
UART3 Data Register
UART3DR
R/W
0
0
0
0
0
0
0
0
406EH
Reserved
–
–
–
–
–
–
–
–
–
–
406FH
Reserved
–
–
–
–
–
–
–
–
–
–
4070H
UART4 Control Register 1
UART4CR1
R/W
–
–
0
0
0
0
0
–
4071H
UART4 Control Register 2
UART4CR2
R/W
0
0
0
0
0
0
0
0
4072H
UART4 Control Register 3
UART4CR3
R/W
–
0
–
–
–
0
0
0
4073H
UART4 Status Register
UART4ST
R/W
1
0
0
0
0
0
0
0
4074H
UART4 Baud Rate Generation Register
UART4BD
R/W
1
1
1
1
1
1
1
1
4075H
UART4 Data Register
UART4DR
R/W
0
0
0
0
0
0
0
0
4076H
Reserved
–
–
–
–
–
–
–
–
–
–
4077H
Reserved
–
–
–
–
–
–
–
–
–
–
4078H
Timer 4 Control Low Register
T4CRL
R/W
0
0
0
–
–
0
0
0
4079H
Timer 4 Control High Register
T4CRH
R/W
0
0
0
0
–
–
–
0
407AH
Timer 4 A Data Low Register
T4ADRL
R/W
1
1
1
1
1
1
1
1
407BH
Timer 4 A Data High Register
T4ADRH
R/W
1
1
1
1
1
1
1
1
407CH
Timer 4 B Data Low Register
T4BDRL
R/W
1
1
1
1
1
1
1
1
407DH
Timer 4 B Data High Register
T4BDRH
R/W
1
1
1
1
1
1
1
1
407EH
Reserved
–
–
–
–
–
–
–
–
–
–
407FH
SPI2 Data Register
SPI2DR
R/W
0
0
0
0
0
0
0
0
Table 8-10 Table 8.4 XSFR Map (Continued)
