9.2 Geometry User Interface
The following table lists the features that are found based on the
selected features:
Items Find Point Find line Find Arc
1 Line End points of the given line Given a distance, lines parallel to
the given line; lines perpendicular
to the given line through its end
points.
1 Arc Center point, end points. Given an angle, all lines tangent to
and through the center point of the
arc.
If angle is not specified, gives lines
from the end points to the center
point.
Complimentary arc.
2 Points Midpoint between the given
points.
Line between the given points Given a radius, all arcs through the
given points.
If radius is not specified, gives you
two arcs, each tangent to both
points with the midpoint as its
center point.
1 Point
1 Line
Point on the given line which, with
the given point, would form a line
perpendicular to the given line.
Line through the given point, one
parallel and one perpendicular to
the given line.
Given a radius, all arcs through the
given point and tangent to a given
line.
If radius is not specified, gives you
two arcs, each tangent to the
given line with the given point as
its center point.
1 Point
1 Arc
Points which, with the given point,
would form lines tangent to the
given arc and the shortest line
from the given point to the given
arc.
Lines through the given point
tangent to the given arc, and the
shortest line through the given
point to the given arc.
Given a radius, all arcs through the
given point and tangent to the
given arc.
If radius is not specified, gives you
all arcs tangent to the given arc
with the given point as its center
point.
2 Lines Intersection point of the given
lines.
Line that bisects the angle formed
where the given lines intersect;
line perpendicular to the bisector.
Given a radius, all arcs tangent to
both given lines
1 Line
1 Arc
Point where given line intersects
given arc.
Lines perpendicular to the given
line and tangent to the given arc;
shortest line to the given arc
which is perpendicular to the given
line.
Given a radius, all arcs tangent to
the given line and the given arc.
2 Arcs Intersection points. Lines tangent to arcs; shortest line
between arcs.
Given a radius, all arcs tangent to
both arcs.
