10.1 Setup
Feed rate
The parameters set here will be used as the default by MILLPWR
G2
and will only change if it is modified in any of the milling functions
dialogue.
 Highlight the Default field, and specify the inch per minute. Also
select the unit of measure, Inch or MM by pressing the appropriate
soft key.
 Next, highlight the Dry Run field, and enter the inches per minute
that is required. The default is 80 IPM.
 Highlight the Max Override field, and enter the maximum percent
override at full potentiometer.
 Highlight the Full Cut Override field. Enter the override percentage
to be applied to the feed rate when making full cuts in pocket steps.
Display
When drilling a hole, the Number of Cycles refers to the number of
times the drill retracts to clear the debris from the hole. If Distance is
used instead, it would mean how deep the drill plunges before it
retracts.
Similarly, if milling, and using a flat end mill, Distance will mean the
depth of each pass. Number of Cycles will mean how many times the
end mill make a pass, cutting material away each time.
 Highlight the Peck/Pass field, and enter either the Number of Cycles
or the Distance between each cut. This applies to the Z axis depth
of cut.
 Highlight the Stepover field, and enter either the Percentage of the
of the tool’s diameter, or a Distance to be used for milling pockets.
 Highlight the Angles field and select Degrees, or DMS.
 Highlight the Res. Inch and Res. MM fields to select the desired
display resolution for the DRO display.
 Highlight the Manual Z field to define the action the DRO takes
when a running program and encounters a manual Z operation
(default is Switch to Inc). This switches the DRO to INC mode or to
Do Nothing which performs no action, leaving the DRO in whatever
mode the user has it in. The selected option will be the default for
the dialogues and can only be changed in Job Setup.
 Highlight the Graphics field and set to either On to always show the
field graphic assistant in a step form or set to Automatic for
displaying additional fields when available in place of the graphic
assistant.
The number of pecks or passes is limited to 9999
maximum. The distance is limited to 0.0002” (0.005 mm)
or greater.
