Version 16.10 AF-6600 AF-5000 Series Install Manual 236
3. Locate the downloaded EFIS software file on your computer, most likely in your Downloads folder.
Downloads Folder
EFIS Software File in the folder
4. Move the EFIS software file from your computer to the USB Memory stick.
• Right Click on the EFIS software file in your downloads folder and select Copy
• Click on the USB Memory stick icon on your computer, Right Click and then select Paste
5. Eject the USB Memory stick from your computer.
6. Place the USB Memory stick in the PFD EFIS USB Socket (back of EFIS or extension cord on the
panel). Make sure you only have a single USB Memory stick plugged into the EFIS.
7. Power the PFD EFIS screen using Master Power
8. When the EFIS boots you should get a prompt to UPGRADE SYSTEM SOFTWARE ?
Select YES
If you did not get the UPGRADE SYSTEM SOFTWARE prompt you can force a software load from
the SET > CAL > ADMIN Settings > 26. Upgrade System Menu
To Next Page
