Pitot/Static Test Chart
Altitude - feet
Pressure
Tolerance
±(feet)
ADAHRS
200
ADAHRS
201
Backup
EFIS
−1,000
31.018
20
0
29.921
20
500
29.385
20
1,000
28.856
20
1,500
28.335
25
2,000
27.821
30
3,000
26.817
30
4,000
25.842
35
6,000
23.978
40
8,000
22.225
60
10,000
20.577
80
12,000
19.029
90
14,000
17.577
100
16,000
16.216
110
18,000
14.942
120
20,000
13.75
130
22,000
12.636
140
25,000
11.104
155
Airspeed (kts)
Tolerance
±(feet)
ADAHRS
200
ADAHRS
201
Backup
EFIS
20
25
40
50
75
100
125
150
175
